With M12 direct connection

Mallet

Inka Krischke | Inka Krischke, 26.11.2020, 13:30

With M12 direct connection

Georg Schlegel has expanded the 'Shortron' product family with the Shortron connect with M12 connection.

The M12 direct connection enables simple, quick and safe installation of the control devices, as the locking technology is designed in such a way that it is not possible to mix up or reverse the polarity of the connections. Furthermore, no additional contact element is required as this is already integrated in the switch.
Protection class IP65/IP67 ensures reliable protection against water and dust from both the front and rear.

According to the manufacturer, the installation depth is just 33.7 mm (emergency stop 26.7 mm). The 'Shortron connect' range includes an indicator light, pushbutton, illuminated ring pushbutton, selector and key switch and an emergency stop.
