E-CAD solutions
A new look for the user interface
Suite X is the next generation of Wscad's E-CAD solution, which is designed for cross-trade work in the disciplines of electrical engineering, control cabinet construction, process and fluid technology, building automation and electrical installation.
The newly programmed user interface is designed to increase user-friendliness and ergonomics. High-resolution screens (High DPI) and multi-display technology are supported. The now standard software licensing enables companies and the self-employed to use the modular and scalable solution as required without conversion costs and data disruptions. Anyone who needs new functions or more workstations activates the product key sent to them online and can use the extension immediately. According to the manufacturer, the solution has many interfaces to other E-CAD applications and PLM/ERP systems as well as to production. The new interfaces for bidirectional data exchange with other manufacturers include 'M-Print Pro' from Weidmüller for labeling texts and 'Clip Project Planning' from Phoenix for editing terminal strips. With the latest function of the AR app, fitters can mark wired connections using a tablet or smartphone and save the current status.
